A Real-World Istio Gotcha: HTTPS Proxy and TCP Tunneling

A few days ago, I faced an issue while trying to connect to an external API from a pod in our AKS cluster.

I encountered the following response:

curl -X OPTIONS https://en.wikipedia.org/wiki/Main_Page -I

HTTP/2 404

date: Wed, 24 March 2026 14:00:05 GMT

server: istio-envoy

At first, it wasn’t clear what the issue was. After digging deeper, I understood the root cause.

🔍 What was happening?

• We were using two proxies:

  • Istio sidecar Envoy proxy

  • An HTTPS proxy configured inside the cluster for external API access

• All outbound traffic from an Istio-enabled pod is redirected to the sidecar proxy by default

• Access to external URLs depends on sidecar proxy configuration

🧠 Key realization

• The traffic flow was:

  • App → Istio sidecar → HTTPS proxy → External API

• However, Istio didn’t know how to properly handle this proxy connection

⚙️ Solution approach

One solution was to create and configure a ServiceEntry to allow controlled access to external URLs:

kubectl apply -f - <<EOF
apiVersion: networking.istio.io/v1
kind: ServiceEntry
metadata:
name: proxy
spec:
hosts:
- my-company-proxy.com # ignored as it will rather check for addresses
addresses:
- $PROXY_IP/32
ports:
- number: $PROXY_PORT
name: tcp
protocol: TCP
location: MESH_EXTERNAL
resolution: NONE
EOF

❓ Why use TCP protocol instead of HTTP?

• Applications use HTTP CONNECT to establish connections with HTTPS proxies

• After the connection is established, it becomes a raw TCP tunnel

• Istio sidecar proxy is designed for HTTP-aware traffic

• However, HTTP CONNECT switches the connection into a TCP stream

⚠️ What goes wrong with HTTP?

• If you configure protocol as HTTP:

  • Istio expects HTTP-aware traffic

  • But the actual traffic is raw TCP

• This mismatch leads to:

  • Routing issues

  • 404 errors

✅ Why TCP works

• By specifying TCP:

  • You tell Istio to treat traffic as a raw TCP passthrough

  • Istio stops trying to interpret HTTP semantics

• Essentially:

  • “Don’t inspect this traffic—just forward it”

🌍 Additional config

• location: MESH_EXTERNAL

  • Indicates that the destination is outside the Istio mesh

🚀 Final result

After applying the configuration:

kubectl exec "$SOURCE_POD" -c curl -- sh -c "HTTPS_PROXY=$PROXY_IP:$PROXY_PORT curl https://en.wikipedia.org/wiki/Main_Page" | grep -o "<title>.*</title>"

Output:

<title>Wikipedia, the free encyclopedia</title>

💡 Key takeaway

• HTTP CONNECT turns traffic into a TCP tunnel

• Istio must be configured accordingly

• Use TCP protocol in ServiceEntry when dealing with HTTPS proxies

📚 References

• Istio official documentation

• Github Issue
